Figure 66. Assembling Mounting Bracket Assembly_Pole Type (2)
3 Fix the fasteners to the stud bolts of side by side bracket.
Figure 67. Assembling Mounting Bracket Assembly_Pole Type (3)
Fixing Side by Side Bracket on the Pole
To fix the side by side bracket on the wall, do the following:
Prerequisites
Before proceeding with fixing the side by side bracket for 3-sector on the pole,
ensure that you have the items mentioned in the table below:
Table 24. Parts and Tools for Fixing Side by Side Bracket Assembly_Pole Type
Side by Side Bracket Assembly
To Next Page
