Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 50
Copyright © 2019, All Rights Reserved.
Figure 48. Fixing Mounting Bracket on the Pole (4)
When fixing the mounting bracket on the pole, ensure to check the level of bracket.
After finishing the installation, adjust the level minutely.
When poor leveling happens, adjust the position of fasteners to fix the mounting
bracket.
After fixing the steel band, push the remainder of band inside the mounting
bracket
Lifting RRH
To lift the RRH, do the following:
Lift the RRH with a cherry picker.
If it is level, the bubble of the
spirit level is positioned at the
center of both lines.
