Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 61
Copyright © 2019, All Rights Reserved.
Figure 60. Fixing RRHs on the Pole (2)
3 Fix the unit bracket of the RRH-0 to the mounting bracket using the fastener.
Figure 61. Fixing RRHs on the Pole (3)
Unit Bracket
M6 Torx Screw
1
2
RRH-0
RRH-0
Unit Bracket
Mounting Bracket
1
2
