Samsung RT4401-48A - Figure 46. Fixing Mounting Bracket on the Pole (2); Figure 47. Fixing Mounting Bracket on the Pole (3)

Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 49
Copyright © 2019, All Rights Reserved.
2 Place the mounting brackets to the pole.
Figure 46. Fixing Mounting Bracket on the Pole (2)
3 Fix the mounting brackets to the pole using the steel band.
Figure 47. Fixing Mounting Bracket on the Pole (3)
4 Check the level of each mounting brackets on the pole and adjust the level.
1
2
3
4
1
2
Pole
