Samsung RT4401-48A - Figure 25. Fixing Mounting Bracket on the Pole (1); Figure 26. Fixing Mounting Bracket on the Pole (2)

Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 29
Copyright © 2019, All Rights Reserved.
Figure 25. Fixing Mounting Bracket on the Pole (1)
2 Place the mounting bracket to the pole.
Figure 26. Fixing Mounting Bracket on the Pole (2)
3 Fix the mounting bracket to the pole using the steel band.
1
2
Pole
1
2
Steel Band
Mounting Bracket
