Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 21
Copyright © 2019, All Rights Reserved.
2 Fix the clip on antenna using the fasteners.
Figure 16. Assembling Clip on Antenna (2)
3 Insert port seal into RRH ANT 1, 2, 3, 4 port.
When inserting the port seal to RRH ANT port, take care of the direction.
- The screw thread of port seal should be downwards.
To Next Page
