Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 30
Copyright © 2019, All Rights Reserved.
Figure 27. Fixing Mounting Bracket on the Pole (3)
4 Check the level of mounting bracket on the pole and adjust the level.
Figure 28. Fixing Mounting Bracket on the Pole (4)
When fixing the mounting bracket on the pole, ensure to check the level of bracket.
After finishing the installation, adjust the level minutely.
If it is level, the bubble of the
spirit level is positioned at the
center of both lines.
1
2
3
4
