Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 46
Copyright © 2019, All Rights Reserved.
Figure 44. RRH Swivelling Adjustment (3)
4 Check the tilt and the azimuth using the RF alignment tool, and adjust when
there is an issue.
For detailed instructions of how to use the RF alignment tool, refer to the user
manual per each manufacturer.
Using Tilting Bracket
This section describes the procedure to fix the unit bracket using the tilting bracket.
Fixing Unit Bracket
These instructions for mounting a unit bracket to the RRH apply to all installation
types.
M12 Hex. Nut
1
2
[Left Swivelling Adjustment]
[Right Swivelling Adjustment]
