Cubis MSA User Manual 151
Interfaces
Data Output Format with 22 Characters
When data is output in this format, ID codes with 6 characters will precede data
with a 16-character format. These six characters identify the subsequent value.
Normal Operation
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
K K K K K K + A A A A A A A A A * E E E CR LF
* * * * * * – . . . . . . . . . * * * *
* * * * * * * * * *
K: ID code character
1
) E: Unit symbol character
1
)
*: Spaces See chapter „Mass Unit Conversion“
A: Displayed characters CR: Carriage return
LF: Line feed
Special Outputs
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * – – * * * * * * CR LF
H H
L L
C
*: Spaces L: Underweight
– –: Final readout L L: Underweight in checkweighing
H: Overload C: Adjustment
H H: Overload in checkweighing Draft shield and ionizer status
similar to data output format with
16 characters
Error Message
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * E r r * # # # * * * * CR LF
*: Spaces # # #: Error code number
