Cubis MSA User Manual 91
Calculation
Executing a Task: Calculation “Diameter determination”
t If you haven‘t already done so, go to Task Management.
y The task selection is displayed.
t Touch the „Diameter determination“ task from the Task menu.
y The formula for diameter determination and the density of the sample
(8.3 g/cm
3
) are preset..
t The length of the sample, e.g. 100 mm can be entered using the X variable.
t Touch 5VCTV to begin the calculation.
t The calculation results are displayed.
t To return to the weight value display, touch 9GKIJ.
t You can view both values, the weight and the diameter.
t If you want to carry out additional weighing and calculations using
the same formula, place the sample on the balance and then touch %CNE.
t If you want to carry out additional weighing using a different formula,
touch $CEMBack.
t You can now change the formula and then proceed as described above.
Print via the P key:
N + 0.365387 g
X 100
d + 0.749 mm
