Kingfisher Plus+ Hardware Manual
Dial Option Board Specifications
PSTN Modem / Data
Rate
V.34, 300 to 33600 bps, auto-negotiating
RTU DTE Port Speed
300 – 115200 bps
Line Impedance
600 Ω
Approval
International
Transmit level
-10 dBm
Receive level
-43 dBm to -9 dBm
Dialling
Pulse or Tone
Internal Power
Consumption
165 mA from +5 V
DC
Bus on backplane
Isolation
Maximum working voltage in respect to system earth/ground must
not exceed TNV-2 limits (80 V)
Transient voltage: 5 kV
Recommended
Initialization String
D Option: AT&FE0V0S0=2&W
Original D Option: AT&FE0V0S0=2X0&W (ignores dial tone)
Operating Temperature
-20 to +70 °C
Storage Temperature
-40 to +85 °C
Operating Humidity
5 to 95 % RH (non-condensing)
Compatibility
Can be installed in any of the following ports:
CP-10/11/12/21/30 Port 2 or Port 3
MC-10/11/12/30/31 Port 2 or Port 3
LP-1/2 Port4
LP-3 Port 3 or Port 4
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 106
