Kingfisher Plus+ Hardware Manual
9.2.3 AI-10 Specifications
AI-10 / AI-10-V Analogue Input Module Specifications
Parameter
Hardware v1.x Hardware v2.x
Input Current ranges
1,2
4-20, 0-20, ±20, ±10 mA (software selectable)
Input Voltage ranges
3,4,5
1-5, 0-5, ±2.5, ±5, ±10 V
DC
(software selectable)
Inputs per Module 8
Sub System Isolation
The analogue subsystem of the AI-10 is fully isolated
from the RTU’s digital system.
Isolation 3 kV Transient
Input impedance
AI-10 : 250 Ω standard, > 1 MΩ optional
5
AI-10-V : > 1 MΩ
Input Filter
Cutoff Frequency
1.5 kHz @ -3 dB 9 Hz @ -3 dB
Common Mode Rejection 80 dB minimum 66 dB minimum
Mains Rejection None
42dB minimum @ 50Hz
45dB minimum @ 60Hz
Maximum Input Voltage
±12 V to GND
±12 V differential
±12 V to GND
±24 V differential
Accuracy
± 0.1% @ +25 °C
± 0.25% @ -20 to +70 °C
± 0.1% @ 0 to +50 °C
2,3
± 0.2% @ -40 to +85 °C
2,3
Resolution 16 bit (15 data bits and 1 sign bit)
Output Power Isolated 24 V
DC
, 160 mA maximum
Operating Temperature -30 to +80 °C -40 to +85 °C
Storage Temperature -40 to +85 °C
Operating Humidity 5 to 95 % RH (non-condensing)
Hot Swap
Yes. Module can be swapped while RTU is running. Hot
swap will not cause a Warm Start. Inputs are cleared in
RTU memory while module is removed.
Compatibility
One range setting for all channels when used with a PC-1
or CP-11/12/21 processor.
Individual range setting for each channel when used with a
CP-30 processor.
1
) AI-10 only.
2
) For AI-10 V2.x only unipolar current ranges are recommended for use. Bipolar ranges are not
calibrated for current measurement and their accuracy can reach 1.4% of full scale when used to
measure current.
3
) For AI-10 V2.x only bipolar voltage ranges are recommended for use. Unipolar ranges are not
calibrated for voltage measurement and their accuracy can reach 1.4% of full scale when used to
measure voltage.
4
) Analogue Input channels can be modified from low impedance to high impedance by disconnecting
the 250 Ω channel resistor.
5
) The ±10 V input range can only be used on an AI-10 input channel if the current sensing resistor
has been disconnected. Resistors have already been disconnected in an AI-10-V.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 141
