PS-12 and PS-22 Power Supply Modules Specifications
Mains Power
Input
PS-12-x
PS-22-x
AC Rated Voltage Range
(Maximum Input Current)
100 - 240 V, 50 - 60 Hz
(1.5 A)
Not applicable
DC Rated Voltage Range
(Maximum Input Current)
96 - 340 V
DC
(1.5 A)
20 - 60 V
DC
(4.0 A)
Power Inlet
Connector
PS-12-x
PS-22-x
Terminal Block Plug (7.62 mm)
Phoenix PC 4/3-ST-7.62
Dinkle EC762V-03P
Phoenix GMSTBA 2.5/3-G-7.62
Cable Housing (optional)
Phoenix KGG-PC 4/3
Not available
PCB Header (7.62 mm)
Phoenix PC 4/3-G-7.62
Dinkle ECH762R-03P
Phoenix
GMVSTBR 2.5/3-ST-7.62
‘B’ Input / Output
DC Rated Voltage Range
(Maximum Input Current)
12.0 – 16.0 V
DC
(4.5 A)
Backup Battery Type
Sealed Lead-Acid (SLA)
Maximum Battery Capacity
25 Ah
1
Output Power
Total Rated Output Power
60 W
2
Output Voltage Range
Maximum
Current
Protection
Logic
Control
12 V Backplane
3
10.5 - 15.6 V
4.5 A
Firmware
No
5 V Backplane 5 V ± 5%
3.0 A (v1.3) /
5.0 A (v1.5)
4
Electronic
No
Battery
3
10.5 - 15.6 V 4.5 A
Polyfuse with crowbar
over-voltage and
reverse polarity
protection
No
12 V aux
3
10.5 - 15.6 V 2.0 A
Polyfuse (v1.3) /
Electronic (v1.5)
Yes
24 V Isolated aux
24 V ± 5%
0.25 A
Polyfuse
Yes
Field Connector
Terminal Block Plug (5.0 mm)
WECO 120-M-111/07
Phoenix MSTB 2.5/7-G
PCB Header (5.0 mm)
WECO 120-A-111/07
Phoenix MSTB 2.5/7-ST
