Kingfisher Plus+ Hardware Manual
2.5.2 Backplane Cables
While building an RTU, it may become necessary to organise signals and/or power
connections between backplanes. To implement the required interconnections the cables will
be required that can be either assembled (based on the data on the backplane connectors
provided above) or ordered from Semaphore. The following cables are available for order:
Order Code Description
To be used with Backplanes
(Connectors)
POWER CABLES
BPC-01 Interrack 6-way Power Cable, 0.6 m All (J14 to J14)
BPC-02 Interrack 6-way Power Cable, 1.1 m All (J14 to J14)
COMM CABLES
BAC-01
Interconnect cable, 0.5 m,
8-pin clip on both ends
BA-x (J13/J15 to J13/J15)
BAC-02
Interconnect cable, 1.0 m,
8-pin clip on both ends
BA-x (J13/J15 to J13/J15)
BAC-INT-01
Interconnect cable, 0.5 m,
8-pin clip to 7-pin terminal plug
BA-x (J13/J15) to BA-x-PLUS (J13/J15)
BA-x (J13/J15) to BP-x-PLUS (J13)
BAC-INT-02
Interconnect cable, 1.0 m,
8-pin clip to 7-pin terminal plug
BA-x (J13/J15) to BA-x-PLUS (J13/J15)
BA-x (J13/J15) to BP-x-PLUS (J13)
BAC-PLUS-01
Interconnect cable, 0.5 m,
7-pin terminal plug on both ends
BA-x-PLUS (J13/J15 to J13/J15)
BA-x-PLUS (J13/J15) to BP-x-PLUS (J13)
BAC-PLUS-02
Interconnect cable, 1.0 m,
7-pin terminal plug on both ends
BA-x-PLUS (J13/J15 to J13/J15)
BA-x-PLUS (J13/J15) to BP-x-PLUS (J13)
SPECIAL CABLES
BPC-02-GPS
Interrack 2-way Cable, 1.1 m
(24V / SYNC and GND pins only)
To distribute GPS time-sync pulse
across racks without power distribution
All (J14 to J14)
BPC-SPLIT BPC Splitter Cable, 6-way, 0.1 m All (J14) to 2x BPC-0x / BPC-02-GPS cables
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 29
