Kingfisher Plus+ Hardware Manual
13. RELAY EXPANSION BOARDS
Overview
The Kingfisher Plus+ Relay Expansion Boards are designed to be used in conjunction to the
DO-6 module. The relay boards allow much more flexible use of the DO-6 module due to the
wide range of relay types available.
Each relay board has unique internal wiring. Users should be mindful that they are not
completely pin-compatible. Please refer to individual wiring diagrams for details.
TEL REL 002
• 16 Channel Isolated Relay SPDT for DO-6-x complete with 1.5m cable
• Max Voltage 380 V
AC
, 125 V
DC
, 16 commons (1 common per channel)
• Max Current 16 A @ 250 V
AC
resistive, 16 A @ 30 V
DC
resistive, 0.45 A @
125 V
DC
Inductive.
• 5 kV isolation (Coil to Contact)
• Omron G2R-1-E 12 V
DC
Relay
TEL REL 003
• Relay Board - 16 Channel Isolated Relay SPST for DO-6-x complete with
1.5m cable
• Max Voltage 380 V
AC
, 125 V
DC
, 16 commons (1 common per channel)
• Max Current 8 A @ 250 V
AC
resistive, 8 A @ 30 V
DC
resistive, 1 A @ 125 V
DC
Inductive
• 5 kV isolation (Coil to Contact)
• Omron G2RG-2A4 12 V
DC
Relay
TEL REL 004
• Relay Board - 16 Channel Isolated Relay DPDT for DO-6-x complete with
1.5m cable
• Max Voltage 380 V
AC
, 125 V
DC
, 32 commons (2 common per channel)
• Max Current 5 A @ 250 V
AC
resistive, 5 A @ 30 V
DC
resistive
• 5 kV isolation (Coil to Contact)
• Omron G2R-2 12 V
DC
Relay
Electrical Hazards
Only appropriately qualified and trained personnel can install and
service this equipment.
Always power down input voltages exceeding Safety Extra Low
Voltage (SELV) levels (DC 60 V or AC 42 V
PEAK
relative to system
earth and/or ground) before performing any operation on this
product, including field wiring.
Failure to do so may cause fire and may result in a serious
personnel injury or even death.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 184
