Kingfisher Plus+ Hardware Manual
DI-10 options, ordering info, the main features and / or main specification differences are
summarised in the table below:
Order Code
H/W
version
Target System
Voltage
IEC 61131
types I & III
compliant
High-
speed
inputs
4
GPS
v3.2
1
v4.3
2
12 V &
24 V
3
≥48 V Slave Master
DI-10-1   4
DI-10-1-48
5
 
4
DI-10
  
16

DI-10-48
5
   16 
DI-10-GPS
6
   16  
DI-10-48GPS
5,6
   16  
Notes:
1
) And earlier versions (here and further in this Manual).
2
) And later versions (here and further in this Manual).
3
) Will also work with higher input voltages within the specified input range.
4
) Up to 7 counters in total is currently supported by firmware.
5
) DI-10-48 refers also to DI-10-1-48 and to DI-10-48GPS models further in this
document.
6
) DI-10-GPS refers also to DI-10-48GPS model further in this document.
11.3.3 Theory of operation
Block-diagram of DI-10 v3.2 module is shown on the figure below.
DI-10 v3.2 Block Diagram
