Kingfisher Plus+ Hardware Manual
14.4.3 IO-5 Specifications
IO-5 Analogue / Digital Combinational Module Specifications
Operating Temperature -40 to +85 °C
Storage Temperature -40 to +85 °C
Humidity 5 to 95 % RH (non-condensing)
Output Power 24 V
DC
/ 100 mA max, Isolated
Maximum Working
Voltage on any contact of
the field connector
42.4 V
PEAK
/ 60 V
DC
relative to system (backplane) ground
Hot Swap
Yes. Module can be swapped while RTU is running. Hot swap will
not cause a Warm Start.
ANALOGUE INPUTS
Input Current Ranges 4 - 20 mA or 0 - 20 mA
Input Voltage Ranges * 1 - 5 V or 0 - 5 V *
Inputs per Module 4
Resolution Unsigned 12 bit
Accuracy
(includes Gain, Linearity
and Offset errors)
± 0.25% @ 25 °C
± 0.50% @ -40 to +85 °C
Update Rate 120 ms
Cross-Channel Rejection > 115 dB from DC to 1 kHz
Input Impedance
250 Ω standard
1 MΩ optional *. The internal load resistors can be factory
removed if high impedance voltage inputs are required.
Input Filter
Cutoff Frequency
7 Hz @ -3 dB
AC noise attenuation
16 dB @ 50 Hz
18 dB @ 60 Hz
Output Field Power 24 V
DC
/ 80 mA Isolated
Isolation 5 kV Transient
