semaphore KINGFISHER PLUS+ - 11.2.2 DI-5 Module LEDs

Kingfisher Plus+ Hardware Manual
Block-diagram of the DI-5 module is shown on the figure below.
DI-5 Block Diagram
11.2.2 DI-5 Module LEDs
LED State Description
OK
OFF Module fault (no power)
ON Normal
1 - 16
OFF Digital Input OFF
ON Digital Input ON
