semaphore KINGFISHER PLUS+ - 4.4.3 Backup Battery; Reset to Factory Defaults

Kingfisher Plus+ Hardware Manual
Order
Code
Item
H/W version
v1.6
1
V2.3
2
CP-30-x
3
y
4
BB RAM size 128 KB 512 KB
SDRAM size 32 MB 64 MB
Backup Battery Soldered User Replaceable
Factory Reset
Module has to be removed
from the slot (takes 5 min
waiting time minimum)
From the front of
the module (quick)
Operating Temperature Range -20 °C to +70 °C -40 °C to +85 °C
Maximum current consumption
from +5V
DC
rail on backplane
290 mA 200 mA
Notes:
1
) And earlier versions (referred to as v1.x further in this Manual).
2
) And later versions (referred to as v2.x further in this Manual).
3
) ‘x’ designates a code of the communications option board installed on Port 2.
4
) ‘y’ designates a code of the communications option board installed on Port 3.
Communications Option Boards codes:
Code Short Description Code Short Description
0 No Option Board installed L Private Line 2/4 Wire, FSK, 1200 Baud
A
1
Ethernet, Fibre Optic, 10/100 Mbps R2 Spread Spectrum Radio 900 MHz (AU)
A3 Ethernet, Fibre Optic, 10/100 Mbps R3 Spread Spectrum Radio 2.4 GHz
D PSTN Modem, 38.4 kbps R4 Spread Spectrum Radio 900 MHz (US)
F Serial Fibre Optic T
1
Ethernet, Copper, 10/100 Mbps
H HART Interface T2
1
Ethernet, Copper, 10/100 Mbps
I Serial Isolated RS232/422/485 T3 Ethernet, Copper, 10/100 Mbps
I2 Dual Isolated Serial RS232/422/485
Notes:
1
) Discontinued products.
4.4.3 Backup Battery / Reset to Factory Defaults
CP-30 modules include lithium coin backup battery for Real Time Clock operation and for
preserving content of the battery backed SRAM when power is removed from the module.
Backup battery on v1.x is soldered to the PCB assembly of the CP-30 module. A battery
retainer is used on v2.x, allowing the user to replace the battery without any special tools.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 73
