Kingfisher Plus+ Hardware Manual
5.2.3 MC-10/11/30 Specifications
MC-10/11/30 Communications Module Specifications
Processor
Intel 80C386EX
Word Size
32 bit internal data bus
16 bit external data bus
Clock Speed
25 MHz
BIOS
Yes
Flash Memory
1 MB
Static CMOS RAM
1 MB
RTC (Real-Time Clock)
Yes
WDT (Watchdog Timer)
Yes
Status Indication
Yes
Communications Ports
1-3 (1 fixed, 2 option ports)
Port 1 (RS-232)
300 to 115200 Baud
Ports 2 and 3 (Optional)
For supported port types, please see the
Communications Option Boards
chapter
Communications Protocol
Kingfisher, DNP3, Modbus + many more
MC-10/11/30 modules per RTU
Maximum of 16 ports per RTU
For example, can use 5 MCs if each has 3 ports
Internal Power Consumption
(without Option Boards)
310 mA from +5 V
DC
bus on backplane
Operating Temperature
-20 to +70 °C
Storage Temperature
-40 to +85 °C
Operating Humidity
5 to 95 % RH (non-condensing)
Hot Swap
Yes. Module can be swapped while RTU is running.
However, Hot Swap will cause a Warm Start of the
processor. All ports will be re-initialised and ready for
communications within 6 seconds.
