Kingfisher Plus+ Hardware Manual
4. PROCESSOR MODULES
Overview
The processor module is the core part of any RTU. It is responsible for running user logic
and facilitating inter-module interactions (via backplane) and communications with the
SCADA system and other RTUs and various 3
rd
party devices (via communications ports) as
required. The amount of memory, speed, and flexibility of an RTU is determined by the
processor module selected.
There are three processor modules available in the Kingfisher Plus+ modular RTU range.
Each of them has one resident communications port, with an ability to add up to two
additional communications ports.
Processor modules summary:
Parameter / Feature PC-1 CP-12 CP-30
Processor Speed 16 MHz 40 MHz 166 MHz
Flash Memory 128 KB 512 KB 16 MB
SDRAM - - 32 MB
NV RAM 256 KB 512 KB 512 KB
1
Port 1 (resident) RS-232 RS-232 10BASE-T / 100BASE-TX Ethernet
Optional Ports 1
2
2
3
2
3
Programming Languages Ladder Logic
Ladder Logic
Structured Text, Ladder Diagram, Function
Block Diagram, Instruction List, Sequential
Function Chart and Flow Chart
Notes:
1
) 128 KB for CP-30 v1.x.
2
) See PC-1 Option Boards for available options.
3
) See the Communications Options Boards chapter for available options and compatibility.
Lithium Battery
This product contains a lithium battery. Risk of explosion if battery is
replaced by an incorrect type. Dispose of used batteries in
accordance with local regulations or return to the supplier.
Pile au Lithium
Ce produit contient une pile au lithium. Il y a un risque d’explosion
si la pile est remplacée par un modèle incorrect. Jetez les piles
usagées conformément aux réglementations locales ou retournez-
la au fournisseur.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 61
