Kingfisher Plus+ Hardware Manual
15. ADAPTORS AND CABLES
Overview
A range of adaptor and cable accessories are available for the Kingfisher Plus+ range to
allow for communications interfacing. The adaptor plugs universally adapt to RJ45 to allow
standard CAT5/6 cabling to be used between RTUs, PLCs and communications devices.
Connectivity Example
Reference:
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 225
