Kingfisher Plus+ Hardware Manual
11.2.3 DI-5 Specifications
DI-5 Input Module Specifications
Rated Voltage
+ 12 to 24 V
DC
nominal (supports reverse polarity)
Note: The DI-5-1-48 High Input Voltage module in the Custom Products
chapter supports higher DC input voltages (48 V
DC
nominal)
Inputs per Module 16
Input Characteristics
Impedance
2.7 kΩ
ON-state Voltage
Channels 1 and 2 : 10 to 28 V
DC
maximum
Channels 3 to 16 : 7.5 to 28 V
DC
maximum
OFF-state Voltage
Channels 1 and 2 : 0 to 3.5 V
DC
Channels 3 to 16 : 0 to 3.0 V
DC
ON-state Current 4.3 mA minimum
OFF-state Current 1 mA maximum
ON Response Time
Channels 1 and 2 : 50 µs maximum
Channels 3 and 4 : 500 µs maximum
Channels 5 to 16 : 10 ms maximum
OFF Response Time
Channels 1 and 2 : 50 µs maximum
Channels 3 and 4 : 500 µs maximum
Channels 5 to 16 : 17 ms maximum
Isolation 5 kV Transient
Output Power 12 V
DC
/ 250 mA (3 W) isolated, supplied by module
Operating Temperature -40 to +85 °C
Storage Temperature -40 to +85 °C
Operating Humidity 5 to 95 % RH (non-condensing)
Pulse Totalisation Channels 1 to 4 : 0-65535 Pulses
Pulse Rates /
Frequency
Channels 1 and 2 : 10 kHz maximum
Channels 3 and 4 : 255 Hz maximum
Hot Swap
Yes. Module can be swapped while RTU is running. Hot swap will not
cause a Warm Start. Inputs are cleared in RTU memory while module is
removed.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 152
