semaphore KINGFISHER PLUS+ - 3.2.2 Options and Ordering Info

Kingfisher Plus+ Hardware Manual
PS-x2/PS-x1 modules can be swapped while RTU is running, providing that there is an
alternative power source in the system for the RTU to be powered during such swap – e.g.
another (redundant) PS-xx module.
3.2.2 Options and Ordering Info
Since PS-x1 modules are superseded, this section does not contain ordering information for
PS-11 and PS-21 modules.
Unless explicitly noted, all hardware versions of PS-x2 modules are described in this
manual. The newer PS-x2 version (v1.5) has some differences in the module features and
specifications comparing with its predecessor (v1.3); in particular the available current for the
5V rail has increased from 3 A to 5 A and the operating temperature range has been
extended to -40 °C to +85 °C.
The PS-x2 modules with ‘-C’ suffix in their Order Code have an additional isolated DC-DC
converter board DC-10 installed into the main PS-x2 board. It provides isolated 24 V power
to the 24V
AUX output.
PS-x2 options, ordering info and main specification differences are summarised in the table
below:
Order Code
H/W
version
Mains
Input
Power
24VAUX
power
5 V max
current, A
Operating
temperature, °C
3.0 5.0
3
-20 - +70 -40 - +85
PS-12-0
v1.3
1
100–240 V,
50-60 Hz
or
96-300 V
DC
 
v1.5
2
 
PS-12-C
v1.3
1

 
v1.5
2
 
PS-22-0
v1.3
1
20-60 V
DC
 
v1.5
2
 
PS-22-C
v1.3
1

 
v1.5
2
 
Notes:
1
) And earlier versions (here and further in this Manual).
2
) And later versions (here and further in this Manual).
3
) Linearly derated to 4.0 A from +60 °C to +85 °C.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 38
