Kingfisher Plus+ Hardware Manual
8. IO MODULES OVERVIEW
This chapter contains general overview of and wiring guidelines applicable to IO modules in
the Kingfisher Plus+ range. The types of available IO modules are listed in the table below.
Part Number Description of Module I/O Points
Commons per
Module
ANALOGUE MODULES
AI-1 Analogue Input Module 8 1
AI-10 Analogue Input Module (High Performance) 8 1
AO-3 Analogue Output Module 4 4
DIGITAL MODULES
DI-5 Digital DC Input Module 16 1
DI-10 Digital AC/DC Input Module 16 1
DO-1
Digital Relay Output Module (NO/NC)
8 4
DO-2
Digital Relay Output Module (NO)
16 2
DO-6 Digital Solid State Module 16 2
COMBINATIONAL I/O MODULES
IO-2 Combination Digital I/O Module 16 2
IO-3 Combination Analogue/Digital I/O Module 13 4
IO-4 Combination Analogue/Digital I/O Module 12 3
IO-5 Combination Analogue/Digital I/O Module 13 4
IO Modules Field Connector
Each IO module has a removable 20-terminal I/O connector block mounted on the front of
the module for connections from user devices. This allows the IO module to be swapped
without having to detach the field wiring from the I/O connector. The I/O connector is
secured to the module using two fastening screws as shown on the picture below.
Hardware Manual Version 7.16
