Kingfisher Plus+ Hardware Manual
4.3.4 CP-12 Specifications
PROCESSOR SPECIFICATIONS
Processor
40 MHz x86
Word Size
16 bit data bus
BIOS
Yes
Flash Memory
512 KB
SRAM
512 KB
Battery Type
Lithium Primary (not rechargeable)
Battery Life
(module unpowered)
7 years @ 25°C
Real-time Clock Accuracy
1 minute per month (+/- 20 ppm)
Watchdog timer
Yes
Status Indication
Yes
Communications Ports
1-3 (1 fixed, 2 option ports)
Port 1 (RS-232)
300 to 115200 Baud (factory default 9600 8-N-1)
Ports 2 and 3 (Optional)
For supported port types, please see the Option Boards
chapter
Configuration Software
Toolbox 32
RTU Address Range
1 – 249 (expandable to 2000 by using multiple masters)
Communications Protocol
Kingfisher, Modbus + many more
Default Data Format
8 data bits, no parity, 1 stop (8, N, 1)
Analogue Block Processing
Yes
PID Block Processing
Yes
Redundancy
Yes. Two CP-12 modules can be installed in the one RTU.
One processor module must be installed in an odd numbered
slot and one in an even numbered slot.
Internal Power Consumption
(without Option Boards)
150 mA from +5 V
DC
bus on backplane
I/O Bus Data Rate
250 kbps
CM Bus Data Rate
83 kbps
Operating Temperature
-20 to +70 °C
Storage Temperature
-40 to +85 °C
Operating Humidity
5 to 95 % RH (non-condensing)
Hot Swap
Yes*
*) When 2 processors are present on the backplane, one processor can be swapped while the RTU
is still running. However, a hot swap will cause a Warm Start of the remaining processor. All ports
will be re-initialized and ready for communications within 6 seconds. New data received during the
changeover may be lost. To preserve data and for more information please see the Redundancy
appendix in the Toolbox 32 manual.
