3.2.7 PS-x1 Specifications
PS-11 and PS-21 Power Supply Modules Specifications
Mains Power
Input
PS-11-x
PS-21-x
AC Rated Voltage Range
(Maximum Input Current)
100 - 240 V, 50 - 60 Hz
(1.5 A)
Not applicable
DC Rated Voltage Range
(Maximum Input Current)
96 - 340 V
DC
(1.5 A)
20 - 60 V
DC
(4.0 A)
Power Inlet
Connector
PS-11-x
PS-21-x
Mains Connector Plug
Phoenix PC 4/3-ST-7.62
Dinkle EC762V-03P
JST VHR-3M (housing)
JST SVH-41T-P1.1 (contact)
Cable Housing (optional)
Phoenix KGG-PC 4/3
Not available
Mains Connector PCB Header
Phoenix PC 4/3-G-7.62
Dinkle ECH762R-03P
JST S3P-VH
‘B’ Input / Output
DC Rated Voltage Range
(Maximum Input Current)
12.0 – 15.0 V
DC
(4.5 A)
Backup Battery Type
Sealed Lead-Acid (SLA)
Maximum Battery Capacity
25 Ah
1
Output Power
Total Rated Output Power
60 W
2
Maximum total current
4.5 A
Output Voltage Range
Maximum
Current
Protection
Logic
Control
12 V Backplane
3
10.2 - 14.4 V 4.5 A
PS-11 : Electronic
PS-21 : No
No
5 V Backplane
5 V ± 5%
3.0 A
Electronic
No
Battery
3
10.8 - 15.0 V
4.5 A
Polyfuse
4
No
12 V Auxiliary
3
10.8 - 15.0 V 4.0 A
PS-11 : Electronic
PS-21 : No
Yes
24 V Auxiliary Isolated
24 V ± 5%
0.25 A
Polyfuse
Yes
Field Connector
Terminal Block Plug (5.0 mm)
WECO 120-M-111/07
Phoenix MSTB 2.5/7-G
PCB Header (5.0 mm)
WECO 120-A-111/07
Phoenix MSTB 2.5/7-ST
