Kingfisher Plus+ Hardware Manual
PS-11 and PS-21 Power Supply Modules Specifications
Monitoring
Parameter
Range
Accuracy
Rail Voltage
(12 V
BP
, Battery, 12 V
AUX
)
9.0 - 15.6 V ± 2%
Supply Current
0.0 - 4.0 A
± 10%
Battery Current
5
±4.0 A
± 10%
External Temperature
-20 to +80 °C
± 2 °C typ @ 25 °C
Internal Temperature
0 to +80 °C
± 2 °C typ @ 25 °C
Safety Isolation / Maximum Working Voltage
Primary (Mains) to Secondary
(Backplane, Field, Functional
Earth) isolation
3.0 kV
RMS
/ 4.2 kV
DC
In accordance with IEC 60950
Maximum Working Voltage on
any contact of the Field
Connector
42.4 V
PEAK
/ 60 V
DC
relative to system (backplane) ground
Environment
Operating Temperature
-20 to +70 °C
Storage Temperature
-40 to +85 °C
Operating Humidity
5 to 95 % RH (non-condensing)
Notes:
1
) Batteries exceeding quoted maximum capacity can be used. However, full charging
and estimated battery charge level cannot be guaranteed.
2
) For ambient temperatures for up to +50 °C.
3
) Nominal value is 13.8 V @ 25°C. These voltages are electrically linked and are
controlled by the PS-x1 module when charging a battery. They will depend only on
backup battery voltage when RTU runs from the battery (e.g. when there is a Mains
outage).
4
) In addition to polyfuse, the PS-11 module has a crowbar over-voltage and reverse
polarity protection. The battery input of the PS-21 module does not have auto-resetting
protection against reverse-polarity. Please ensure the battery is connected correctly.
5
) Negative: current flows from the battery (battery supplies power)
Positive: current flows to the battery (battery is charged).
