Kingfisher Plus+ Hardware Manual
HART Option Board Specifications
Baud-rate
1200 Baud, Half Duplex
Modulation
Bell 202
Logical Frequencies
1 = 1200 Hz
0 = 2200 Hz
Internal Power
Consumption
20 mA from +5 V
DC
Bus on backplane
Maximum No. HART
Devices
15 (multi-drop)
Data Available
HART and loop current for point-to-point
HART only for multi-drop
Isolation
Maximum working voltage in respect to system earth/ground
must not exceed TNV-2 limits (80 V)
Transient voltage: 3.88 kV
Operating Temperature
-20 to +70 °C
Storage Temperature
-40 to +85 °C
Operating Humidity
5 to 95 % RH (non-condensing)
Compatibility
Can be installed in any of the following ports:
CP-10/11/12/30 Port 2 or Port 3
MC-30/31 Port 2 or Port 3
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 115
