semaphore KINGFISHER PLUS+ - R2 Spread Spectrum Radio Board Specifications

Kingfisher Plus+ Hardware Manual
Modifications
Use of unauthorised antenna or other changes or modifications not
expressly approved by the party responsible for compliance could
void the user’s authority to operate this product.
Modifications
L’utilisation d’antennes non autorisées ou d’autres changements
ou modifications non explicitement approuvées par la partie
responsable de la conformité pourrait annuler l’autorisation pour
l’utilisateur de faire fonctionner ce produit.
R2 Spread Spectrum Radio Board Specifications
Countries Supported Australia
Frequency 915-928 MHz
Transmit Power 1-1000 mW configurable
Range Indoors 900 m
Range Outdoors 22 km
Range with Yagi Up to 32 km
Data rate — RTU to Radio 9600 bps
Data rate — Radio to Radio 115200 or 9600 bps
Power Consumption 3.7 W maximum
Spread Spectrum Type FHSS (Frequency Hopping Spread Spectrum)
Encryption None
Antenna Connector RPSMA (reverse polarity SMA) Male (on radio)
Receiver Sensitivity -110 dBm @ 9600 bps
Operating Temperature -20 to +70 °C
Storage Temperature -40 to +85 °C
Operating Humidity 5 to 95 % RH (non-condensing)
Compatibility
Can be installed in any of the following ports:
CP-10/11/12/30 Port 2 or Port 3
MC-10/11/12/30/31 Port 2 or Port 3
LP-1/2 Port4
LP-3 Port 3 or Port 4
Please see http://www.digi.com for more information on XTend® 900MHz wireless module
(P/N XTH9-MI-NA) specifications.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 119
