semaphore KINGFISHER PLUS+ - R3 Spread Spectrum Radio Board Specifications

Kingfisher Plus+ Hardware Manual
Modifications
L’utilisation d’antennes non autorisées ou d’autres changements
ou modifications non explicitement approuvées par la partie
responsable de la conformité pourrait annuler l’autorisation pour
l’utilisateur de faire fonctionner ce produit.
R3 Spread Spectrum Radio Board Specifications
Countries Supported International
Frequency 2.4000-2.4835 GHz
Transmit Power 50 mW
Range Indoors 180 m
Range Outdoors 5 km
Range with Yagi Up to 8 km
Data rate — RTU to Radio 19200 bps
Data rate — Radio to Radio 9600 bps
Power Consumption 0.75 W maximum
Spread Spectrum Type FHSS (Frequency Hopping Spread Spectrum)
Encryption None
#
Antenna Connector RPSMA (reverse polarity SMA) Male (on radio)
Receiver Sensitivity -105 dBm
Operating Temperature -20 to +70 °C
Storage Temperature -40 to +85 °C
Operating Humidity 5 to 95 % RH (non-condensing)
Compatibility
Can be installed in any of the following ports:
CP-10/11/12/30 Port 3 only
MC-10/11/12/30/31 Port 3 only
LP-2 Port4
LP-3 Port 3 or Port 4
#
Encryption by special request in the USA only.
Please see http://www.digi.com/
for more information on XStream® 2.4GHz wireless module
(P/N X24-019NMI) specifications.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 121
