LED State Description
OK
ON
Module operating normally
0.5 s ON,
0.5 s OFF
Internal Fault: (module needs repair)
1
OFF
Power off
ERR
1
1 s ON,
1 s OFF
Backplane communications time-out (15 s) expired
(no polling received from the RTU processor module)
0.1 s ON,
1.9 s OFF
Module faulty and needs repair.
OFF
Normal
GPS
1,2
ON
GPS serial port data detected and GPS is synchronised to the GPS network.
1 s ON,
1 s OFF
GPS serial port data detected but the GPS is not synchronised to the GPS
network.
1.8 s ON,
0.2 s OFF
Time Synchronized to another DI-10-[48]GPS (master). This implies that no
GPS is connected to this module so it acts as a DI-10 (slave).
0.2 s ON,
0.2 s OFF
Timing error in GPS slave synchronisation signal. This stays active until the
next properly timed synchronisation signal, which could be a few minutes. This
implies that no GPS is connected to this module so it acts as a DI-10 (slave).
OFF
No GPS detected.
SYNC
1
1.8 s ON,
0.2 s OFF
Time Synchronised to a DI-10-[48]GPS (master).
0.2 s ON,
0.2 s OFF
Timing error in GPS slave synchronisation signal. This stays active until the
next properly timed synchronisation signal, which could be a few minutes.
OFF
No time synchronisation signal detected.
PCON
ON
+12V DC-DC converter on
OFF
+12V DC-DC converter off. No digital input sampling occurs.
1-16
ON
Digital Input ON
(channel input level is above low-to-high threshold)
OFF
Digital Input OFF
(channel input level is below high-to-low threshold)
Notes:
1
) Only hardware v4.3 or later.
2
) Only on DI-10-GPS modules (GPS Master).
