Kingfisher Plus+ Hardware Manual
DI-10 Digital Input Module Specifications
Parameter v3.2 v4.3
Digital Input Timing
ON Response Time (max)
50 µs (DC, Ch. 1-4)
500 µs (DC, Ch. 5-16)
30 ms (AC)
50 µs (DC)
30 ms (AC)
OFF Response Time (max)
50 µs (DC, Ch. 1-4)
500 µs (DC, Ch. 5-16)
30 ms (AC)
50 µs (DC)
30 ms (AC)
Filtering None,1, 3, 10, 30, 100, 250 ms or AC Filter
Frequency, Pulse and Quadrature Counters
Total number of Counters 7 maximum
Maximum Frequency
10 kHz (Ch. 1-4)
1 kHz (Ch. 5-16)
10 kHz
Frequency Counting 1 Hz resolution on any input(s)
Pulse Counting 0-65535 Pulses on any input(s)
Quadrature Counting 0-65535 Pulses on any of the inputs pair(s) 1-2, 3-4, etc.
Hardware Manual Version 7.16
