Kingfisher Plus+ Hardware Manual
Dimensions
253 mm(L) x 90 mm(W) x 70 mm(H)
(280 mm long with 2 end clamps)
Mounting 35 mm DIN rail
Interface Cable Length 1500 mm (for connection to the DO-6 module)
Connection Terminals
Phoenix double height PCB terminal unit arranged in a dual three
way terminal (please see wiring diagram). These terminals can
take wire sizes up to 4 mm
2
.
Relay Part Number
Omron G2R-1-E 12 V
DC
(datasheet is available from http://components.omron.eu/
)
CAUTION! Contacts should be protected with appropriate suppression devices when wired
with inductive loads to increase the service life of relays (please see the
"Switching
Inductive Loads" section for more details). Contacts should also be protected with external
fusing.
#)
CAUTION! If input voltage is expected to exceed Safety Extra Low Voltage (SELV) levels
(DC 60 V or AC 42 V
PEAK
relative to system earth and/or ground) then all used commons
must be connected to a single power source and no other power sources are allowed to be
connected to this module.
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 187
