Kingfisher Plus+ Hardware Manual
Fujicon DO-6 Pin DO-6 Outputs Belden 9431 Cable Color Panduit 20 way header pins
1 Channel 1 Black 1
2 Channel 2 White 2
4 Channel 3 Red 4
4 Channel 4 Green 4
5 Channel 5 Orange 5
6 Channel 6 Blue 6
7 Channel 7 White/Black 7
8 Channel 8 Red/Black 8
9 0 V Green/Black 9
10 0 V Orange/Black 10
11 Channel 9 Blue/Black 11
12 Channel 10 Black/White 12
13 Channel 11 Red/White 13
14 Channel 12 Green/White 14
15 Channel 13 Blue/White 15
16 Channel 14 Black/Red 16
17 Channel 15 White/Red 17
18 Channel 16 Orange/Red 18
19 + 12 V
DC
Blue/Red 19
20 + 12 V
DC
Green/Red 20
