Kingfisher Plus+ Hardware Manual
Revision History
Version
Number
Date Summary
7.0
7.1
7.12
28/10/2011
Update: adaptor ADP-22B (include Wavecom extend)
Update: temp sensor is white / white with a black strip
Update: power requirements of T option board
Update: power calculation tables
Update: Comms option boards selection table
Update: safety warnings
Update: Lenses for PS-12 and PS-22
Update: Lens for MC-31
Proposed ‘Linked Backplane Example’ chapter removed
Update: Various errors found in first release
7.13 3/9/2012
Corrected IO-5 power consumption
Added CP-12 power consumption
Added CP-30/MC-30/MC-31 to compatibility chapter
Corrected various spelling and grammatical mistakes
Outlined A3 / T3 simultaneous master and slave limitation in
rare use-cases
Added IO-5 Power Consumption
Corrected RJC-ADP30 Diagram, RJ45 wiring error corrected
Updated T3 temp range
Added block diagrams for all IO Modules
Added Option Board installation guide
PS-x2 nominal voltage at low temperatures extended to 15°C
after further testing
Logo updated
7.14 24/10/2014
Added new modules.
Added block diagrams for various modules.
Modules specifications reviewed and updated.
Safety warnings updated.
Non-operational hyperlinks updated.
Logo and the document style updated.
Various corrections and updates.
7.15 18/11/2014
MC-10/11/30 modules added.
PS-11 and PS-21 modules added.
Option Board T2 added.
Various corrections and updates.
