IO Module typical current consumption (mA at 13.8 V
DC
)
Part
number
24 V
Converter
OFF
24 V
Converter
ON
Extra
current
per
Analogue
Input ON
Extra
current
per
Analogue
Output
ON
Extra
current
per
Digital
Input ON
Extra
current
per
Digital
Output
ON
Absolute
maximum
current
draw
AI-1 11 80 +50 [+0] - - - 480
AI-10 v1.x 25 185 +62 [+3] - - - 681
AI-10 v2.x 15 50 +38 [+0] - - - 354
AO-3 5 180 - +50 - - 380
DI-5 23 - - - +7 [+2] - 135
DI-10 40 - - - +11 [+5] - 216
DO-1 7 - - - - +31 255
DO-2 7 - - - - +13 215
DO-5/6 3 - - - - +1 19
IO-2 5 - - - +7 [+3] +12 157
IO-3 10 53 +46 [-1] +42 +10 [+1] +12 367
IO-4 8 44 +44 [-2] - +9 [+1] +12 228
IO-5 13 97 +89 [0] +42 +14 [2] +12 389
Note: Values shown are for inputs powered by the IO module itself when power is available
from the 13.8 V
DC
supply. Values in square brackets ‘[ ]’ denote current consumption when
inputs are powered by an external supply.
Relay Output Modules power consumption:
Item Per Output Maximum Consumption
TEL-REL 02 530 mW 8.5 Watts
TEL-REL 03 800 mW 12.8 Watts
TEL-REL 04 530 mW 8.5 Watts
Superseded Communications Modules current consumption (mA at 13.8 V
DC
)
Item CP-11 / MC-11 / MC-30
Basic Module, no options 165
Superseded IO Module typical current consumption (mA at 13.8 V
DC
)
Part
number
24 V
Converter
OFF
24 V
Converter
ON
Extra current
per Analogue
Input ON
Extra current
per Analogue
Output ON
Extra current
per Digital
Input ON
Extra current
per Digital
Output ON
Absolute
maximum
current draw
AO-2 11 115 - +55 - - 335
