Kingfisher Plus+ Hardware Manual
CP-xx and MC-xx Option Boards typical 5 V Rail consumption (mA from 5 V
DC
)
Option Board Type Port label Consumption
ACTIVE
A3 Fibre Optic Ethernet A3 600
Dial (PSTN) D 165
Fibre Optic Serial F 50
HART H 20
Isolated Serial (RS-232) I 70
Dual Isolated Serial I2 95
Private Line or Analogue Radio Interface L 20
2.4 GHz (50 mW) Spread Spectrum Radio:
Transmitting
Receiving
R3 100
85
900 MHz (1 W) Spread Spectrum Radio:
Transmitting
Receiving
R2 / R4 670
100
T3 Ethernet T3 300
SUPERSEDED
10/100 Base-T Ethernet ENET-T 130
100 Base-FX (Fibre Optic) Ethernet ENET-A 650
10/100 Base-T Ethernet ENET-T2 310
10/100 Base-T Ethernet ENET-E 0 idle / 850 max
Serial (RS-232) SER-S 5
Line (original version) L(1) 120
Image Capture J 1000
Hardware Manual Version 7.16
