Kingfisher Plus+ Hardware Manual
LED State Description
P2 (Port 2) and P3 (Port 3) LEDs:
Ax and Tx (Ethernet) options
Tx
4
TxD / 10ACT
3
Flashing Data activity (transmit or receive) at 10 Mbps.
OFF No data activity at 10 Mbps.
Rx
4
RxD / 100ACT
3
Flashing Data activity (transmit or receive) at 100 Mbps.
OFF No data activity at 100 Mbps.
RTS
4
RTS / LINK
3
ON Linked at either 10 or 100 Mbps.
OFF Port not connected or no Ethernet link established.
CD
4
DCD / COL
3
ON Ethernet collision(s) detected.
OFF No collisions detected.
Notes:
1
) Progressively set ON during booting sequence.
After a successful start-up: OK is ON; F1 and F2 are OFF; F3 is ON (for active processor)
or flashing (for standby processor).
2
) Flash rapidly to indicate firmware upgrade error.
3
) CP-30 v2.x only.
4
) CP-30 v1.x only.
