Kingfisher Plus+ Hardware Manual
LED State Description
Rx
4
RxD /
100ACT
3
Flashing Data activity (transmit or receive) at 100 Mbps.
OFF No data activity at 100 Mbps.
RTS
4
RTS / LINK
3
ON Linked at either 10 or 100 Mbps.
OFF Port not connected or no Ethernet link established.
CD
4
DCD / COL
3
ON Ethernet collision(s) detected.
OFF No collisions detected.
Notes:
1
) Progressively set ON during booting sequence.
After a successful start-up: OK is ON; F1, F2 and F3 are OFF.
2
) Flash rapidly to indicate firmware upgrade error.
3
) MC-31 v2.x only.
4
) MC-31 v1.x only.
