SGM Technology for lighting GB
Pilot 3000 Us
er’s Manual 1.00
- 9 -
2 QUICK START
This chapter is intended for those users wanting a rapid effective approach to the console, in order
to learn basic programming procedure in a short time
Pilot 3000 allows programming maximum 999 Cues for each single Register (Cue-List).
These Playback Registers are 20 for each single Page, and the total available Pages are 20.
This chapter explains what to do by means of the following points:
Quick Pilot 3000 setup
Basic programming of a Cue.
Preparing a Cue-list on Playback Registers
Playback of a Cue-list
2.1 Setup
Connect the DMX signal cables.
C
onnect the console to the mains and turn the system ON.
Shouldn't be any previous configuration appearing, push the Menu key and then Setup.
Select Address Patch to enter the Console patching area.
Select the Manufacturer brand name (e.g. SGM) which contains the fi ture needed, the list of
fixtures available will be displayed by the 2 left hand columns on he touch panel. The list can
be vertically scrolled through the use of the encoder Wheel 1 nam d as Brands Scroll
Select the required fixture (e.g. Giotto Wash 400).
Encoder Wheel 2 will be used to set the total amount f fix ures required; whilst Encoder Wheel
3 will enable to set the DMX Universe (A or B) linked to he fixtures patched. Encoder Wheel 4
will be used to set the DMX starting address for the fi st fixture patched.
Push OK to confirm, wait for the white progress bar to store the new Patch settings.
Repeat the above actions should any other fixtu es need to be patched.
In the case of patching for different br ds f xtures, push the Brands key to access the list of
the Manufacturer Brand names.
Push Done twice on the touch panel to enter the programming area.
