1 INTRODUCTION
1.1 System Characteristics
Thank you for having chosen the SGM Pilot 3000
Pilot 3000 is a lighting Console dedicated to the control of both conventional and automated lighting
fixture of any kind. By means of its two DMX-512 Universes, it is possible to control the timing and
running modes of any kind of fixture available on the market thanks to a comprehensive fixture
library that can be updated on an on-going basis. This manual describes all the Pilot 3000 features
available with Software version1.0.
Future software updates along with the relative documentation, can be downloaded from the web
site at www.sgm.it.
Pilot 3000 can be also controlled by external trigger sources via MIDI, SMPTE or DMX, for nning in
synchro mode the shows being programmed on board.
1.2 S
afety information
To ensure correct use of the unit, follow this manual's instructions closely.
Connect the mains cable supplied to the console, after ensuring that it's correctly wired and
appropriately grounded.
Make certain that the mains supply is suitable (between 90 and 250 Volts, 50/60 Hz) and
protected against overload or earth leak risks
Do not use the system in adverse weather conditions, such s ain or temperatures of over
40°C
Always use the units case when transporting it
Handle the unit carefully, avoiding bumps or sudde ch ges in temperature.
Console repairs or maintenance must only be carr ed out by authorized maintenance personnel;
the guarantee will be considered null if unautho ized personnel tamper with the console.
Do not spill liquids (beverages, etc.) on the fr t panel.
Do not use pointed or blunt objects whil using the touch-screen.
Use only a dry cloth for cleaning. Avoid using solvents or stain/grease removers.
Following these instructions through ime will ensure your console a long reliable life!
1.3 U
sing the manual
This manual explains operati ns for using the console with the software version shown on the frontispiece.
SGM Technology for Light g Spa reserves the right to make any variations without prior notice.
To allow an easier consultation to the utmost according to needs, the manual is divided into various areas.
Quick start: de cribes fundamental operations enabling the console to be used immediately
System architecture: describes main hardware and software components.
System setup: describes how to configure the Pilot 3000 before starting a show
Basic programming: gives all the necessary explanations for effective programming and
pla back of relatively simple shows.
Shape Engine: describes all the functions of the effects engine.
Advanced programming: describes all the functions of the console for sophisticated
programming – ideal for expert users.
Throughout this manual:
This format is used to show a physical key on the console.
This format is used to show a soft (display) key.
