5.4 To store a Manual-Cue
Pilot 3000 is equipped with a set of 6 Controllers dedicated to Playback which can be freely configured.
As default the Controllers manage the Intensity and the flash of the first 6 correspondent Playback
Registers of each of the 20 Pages.
As described in the previous chapters (Pilot 3000 Setup -> Slider Configuration) it is possible to set up
some or all the Controllers for the managing of single Cues (Manual CUE), with an easy and immediate
access. The Playback of each Register gives the access from a minimum of one Manual-Cue to a maximum
of 6 different Manual-Cues accordingly to the configuration chosen.
ATTENTION!!
Version 1.0 of Pilot 3000 does not allow the Manual Cues configuration for all the available Regist rs (400),
but only of the first 20 that is the ones related to the page 1.
Future development will allow the extension of the Controllers configurations for both the single Cue and all
the Registers.
To store a Manual Cue:
Proceed to the Attributes editing of the fixture desired as already described
Press the STORE key
Press “function key” of the addressing Controller
Insert the Manual-Cue name using the alphanumeric keyboard on the Touch panel appearing later on
the display LCD.
Confirm with Enter
To verify a Manual Cue just registered, simply:
Press twice the CRL ALL key to turn off the editor.
Activate the Manual-Cue by means of the point r related to the Controller.
