GB SGM Technology for lighting
User’s Manual 1.00 Pi
lot 3000
- 68 -
5.3 Store of Cue or Cue-List
Once programmed through the editor the scene desired, you have to save it into Pilot 3000 in order to
activate it when necessary. Pilot considers “Cue” a status of Attributes stored, restorable, when necessary,
in Playback phase.
Pilot 3000 controls through the Playback Registers all the Cues saved in a show.
The Console is internally equipped with 20 Registers for each page, for a maximum of 20 pages; 400
Registers in total.
Before saving a status of Attributes in a Cue, it is necessary to choose which Register will control the Cue
you are going to save.
It is possible to associate to each Register the control of one ore more Cues, until a maximum of 999 Cues
All the Cues of a List will be activated in phase of Playback by repeatedly pressing the Register key
In the following paragraphs we will see how selecting a Register on different pages and how storing the
Cues.
CHOICE OF THE REGISTER
T
he choice of the Register where you want to store the Cue can be affected in many ways by means of the
SELECT key located in the lower side of the editor keypad.
The SELECT key enables the switching on of the Register LED key currently selected.
To select a Register different from the current one:
press SELECT .
press the key of the Register you are going to select.
This operation has to be carried out in a time not over 4 seconds (Sell time out); otherwise the “Select”
status of the Registers is automatically disabled and brought back to its normal Playback status.
The Select status of the Registers is indicated by the LED linking of the SELECT key.
Alternatively, it is possible to select a Register by r peatedly pressing the SELECT key in order to look
through the selection along the Register set of the c rr nt page.
Wait the time-out for the selection confirmatio .
