SGM Technology for lighting GB
Pilot 3000 Us
er’s Manual 1.00
- 19 -
The parameters which can be assigned to the Encoder Wheels are strictly related to the software
section used while operating with the Pilot 3000.
When operating within the SETUP section, it is possible to assign to the Wheels the following
parameters:
Brand scroll (Address patch menu)
Patch scroll (Address patch menu)
Fixture scroll (Address patch menu)
Number of fixture (Address patch menu)
DMX output selection (Address patch menu)
First Address (Address patch menu)
Attribute scroll (Attribute config. menu)
Fixture select (Attribute config. menu)
Change Attribute (Attribute config. menu)
Options (Options menu)
When operating within the EDITOR section, it is possible to assign to the Wheels the following
parameters:
All the fixture’s attributes (Intensity-PanTilt-Color-Gobo-Prism-Blad )
All the parameters available into the Shape-Engine (Size-Speed S read)
When operating within the PLAYBACK section, it is possible o assign to the Wheels the following
parameters:
Delay time for each single Cue of each individual Cue- ist
Fade-in time for each single Cue of each individua Cue-List
Wait time for each single Cue of each individual Cue-List
Fade-out time for each single Cue of each ind vidual Cue-List
SPEED (Bpm) of each single Chase
FADE (percentage) of each single Cha e
Master Intensity for the active C e li t
SIZE of Shape-Engine effect ap lied to Cues
SPEED of Shape-Engine effects applied to Cues
LIVE CUE-LIST Scroll
