19
HDMI OUT
HDMI
IN
HDMI
OUT
(DC 5V 900mA)
ARC
Preparation
Using digital audio output
Itispossibletooutputaudiothroughthe
DIGITAL
AUDIO OUTPUT
terminal.PCMorBitstream(Dolbyor
DTSDigitalaudio)outputsfromtheterminal.
Connecting to the Network
Seepages75to76.
Insert a SD/SDHC memory card
Itprovidesaccesstophotos,video,music,andother
lesinSD/SDHCmemorycards.
Insert a SD/SDHC memory card that stores your files
into the SD slot. Refer to the method of playing files
stored in the multimedia device specified on Page 84
for details.
To optical digital input of
external audio devices
Opticalbrecable
(commercially
available)
NOTE
• TheDIGITALAUDIOOUTPUTterminalusuallyoutputsthe
same audio from the speakers. (The audio of the content
youareviewingisoutputfromtheterminal.)
• TheDIGITALAUDIOOUTPUTterminaldoesnotoutput
somesignals,dependingondevicesandsoftware.
Connecting a USB hard disk drive (HDD)
YoucanuseUSB3(HDD)terminalwhenconnectingaUSB
harddiskdrive.
USB hard disk drive
Connecting an AV amplifier
Set Top Box (STB)
HDMI-certiedcable
(commerciallyavailable)
NOTE
• Iftheimageisnotinsyncwiththeaudio,checkthesettings
of the connected surround system.
• LettingtheTVoutputtheaudiotoanAVamplier:
- WhenyouconnectARC-compatibleequipment,usethe
HDMI3(ARC)terminal.
- Iftheequipmenttobeconnectedisnotcompatiblewith
theARC,connectanopticalbrecable.
When using RGB cable (commercially
available) connecting to a PC (see page 72 )
NOTE
•
Macintosh adaptor may be required for use for some
Macintosh computers.
PC
SD/
SDHC
NOTE
• Insertthememorycardintotheslotinthedirectionshown
inthegure.
•
The SD slot supports SD and SDHC memory cards.
However some memory cards may not be supported.
•
This product supports memory cards with a maximum
storage of 32 GB. We recommend that you use a memory
card with at least a speed of Class 4 for a higher read-write
speed, thus guaranteeing the system performance.
•
Unplug the memory card after you have safely unloaded it
or the TV has been turned off.
•
Do not unplug the memory card while data is being
transferred. Otherwise the TV may malfunction.
•
Regularly back up data in the memory card to prevent data
corruption or operating errors of the TV. (SHARP shall not
bear any responsibility for data corruption or destruction.)
