MX-3114N SIMULATION 6 – 10
2-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the loads
in the automatic document feeder and the
control circuit.
Section
RSPF
Operation/Procedure
1) Select a target item of the operation check with the touch panel
key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
3
3-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and the detectors in the finisher and
the control circuit.
Section
Finisher
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
Inner finisher (MX-FN17)
3-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the load in
the finisher and the control circuit.
Section
Finisher
Operation/Procedure
1) Select the item to be operation checked with the touch panel
key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
Inner finisher (MX-FN17)
3-10
Purpose
Adjustment
Function (Purpose)
Used to adjust the finisher.
Section
Finisher
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
Display Content
SPUM_F RSPF paper feed motor (normal rotation)
SPUM_R RSPF paper feed motor (reverse rotation)
SPFM_F RSPF transport motor (normal rotation)
SPFM_R RSPF transport motor (reverse rotation)
SPRS Paper exit roller pressure control solenoid (RSPF)
SRRC Registration roller clutch (RSPF)
STMPS Stamp solenoid
Display Content
FABHS Paper alignment belt HP sensor
FAPHPS_F Paper alignment plate HP sensor F
FAPHPS_R Paper alignment plate HP sensor R
FDRPS Paper exit roller position sensor
FDTLLS Paper exit tray lower limit sensor
FDTPD Delivery tray paper detector
FDTULS Paper exit tray upper limit sensor
FFL Fan lock signal
FPCHPS Punch home position sensor
FPD Punch unit detection (connector)
FPDFS Punch dust sensor
FPES1 Punch paper edge sensor 1
FPES2 Punch paper edge sensor 2
FPES3 Punch paper edge sensor 3
FPES4 Punch paper edge sensor 4
FPES5 Punch paper edge sensor 5
FPES6 Punch paper edge sensor 6
FPES7 Punch paper edge sensor 7
FPHPS Punch unit home position sensor
FPLD1 Paper height detector 1
FPLD2 Paper height detector 2
FPMRS Punch motor rotation sensor
FPMS Punch mode sensor
FPPD1 Paper entry detector
FPTS Punch timing sensor
FSED Staple empty detector
FSHPS Staple HP sensor
FSLD Staple lead edge detector
FSSHPS Stapler shift home position sensor
FSSS Staple safety sensor
FSSW Safety switch
FSTPD Staple tray paper detector
FTPS Tray position sensor
Display Content
FCF Cooling fan
FDRLM Paper exit roller lift motor
FPAM_F Paper alignment motor F
FPAM_R Paper alignment motor R
FPAS Paper alignment solenoid
FPDM Paper exit motor
FPGS Paper gate solenoid
FPLDS Paper height detector solenoid
FPM Punch motor
FPS Paddle solenoid
FPSM Punch shift motor
FPTM Paper transport motor
FSM Staple motor
FSSM Stapler shift motor
FTLM Tray lift motor
Display Content
