MX-3114N SIMULATION 6 – 12
4
4-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and detectors in the desk, and the
control circuit of those.
Section
Desk
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
Desk
Tandem LCC (MX-DE20)
4-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the loads
in the desk, and the control circuit of those.
Section
Desk
Operation/Procedure
1) Select the load item that is required to operation check with the
touch panel key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
Desk
Tandem LCC (MX-DE20)
4-5
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the paper
feed desk paper transport clutch (DTRC) .
Section
Desk
Operation/Procedure
Check the ON operation
Press the button of the code name for checking the ON operation.
Checking is started. When the operation is normal, the button on
the display is highlighted. When it is abnormal, the button is not
highlighted.
Check the OFF operation
Press the highlighted button which is ON.
When the operation is normal, the highlighted button on the display
returns to the normal display. When it is abnormal, the highlighted
display is maintained.
5
5-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the display,
LCD in the operation panel, and control cir-
cuit.
Section
Operation panel
Operation/Procedure
The LCD is changed as shown below.
The contrast changes every 2sec from the current level to MAX ï‚®
MIN ï‚® the current level. During this period, each LED is lighted.
The LCD display contrast change and the LED lighting status are
checked.
5-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of the heater
lamp and the control circuit.
Section
Fusing
Operation/Procedure
1) Select the item to be operation checked with the touch panel
key.
2) Press [EXECUTE] key.
Display Content
D1MDC Tray 3 installation detection connector
D1PPD Tray 3 paper transport detector
D1ULD Tray 3 upper limit detector
D1PED Tray 3 paper empty detector
D1PQD Tray 3 remaining paper quantity detector
D1PRED1 Tray 3 paper rear edge detector 1
D1PRED2 Tray 3 paper rear edge detector 2
D1PRED3 Tray 3 paper rear edge detector 3
D1PRED4 Tray 3 paper rear edge detector 4
D2MDC Tray 4 installation detection connector
D2PPD Tray 4 paper transport detector
D2ULD Tray 4 upper limit detector
D2PED Tray 4 paper empty detector
D2PQD Tray 4 remaining paper quantity detector
D2PRED1 Tray 4 paper rear edge detector 1
D2PRED2 Tray 4 paper rear edge detector 2
D2PRED3 Tray 4 paper rear edge detector 3
D2PRED4 Tray 4 paper rear edge detector 4
Display Content
DPFD1 Tray 4 paper pass detector
D1LUD Tray 3 upper limit detector
D1PED Tray 3 paper empty detector
D1PQD Tray 3 remaining paper quantity detector
D1PPD1 Tray 3 paper pass detector 1
D1PPD2 Tray 3 paper pass detector 2
D2LUD Tray 4 upper limit detector
D2PED Tray 4 paper empty detector
D2PQD Tray 4 remaining paper quantity detector
DCDT Tandem tray insertion detection
Display Content
D1LM Tray 3 lift-up motor
D1PFC Tray 3 paper feed clutch
D2LM Tray 4 lift-up motor
D2PFC Tray 4 paper feed clutch
DPFM Desk transport motor
DPTRC Desk paper transport clutch
Display Content
DPFM Desk paper feed motor
DPTRC Desk paper transport clutch
D1LM Tray 3 lift-up motor
D1PFC Tray 3 paper feed clutch
D1PUS Tray 3 paper feed solenoid
D2LM Tray 4 lift-up motor
D2PFC Tray 4 paper feed clutch
D2PUS Tray 4 paper feed solenoid
Button Content
DTRC Desk transport clutch
Display Content
