Sharp MX-2314N Service Manual

MX-3114N SIMULATION 6 – 14
6-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the trans-
port unit and the control circuit.
Section
Process (Transport)
Operation/Procedure
1) Select the operation mode with the mode select button.
2) When [EXECUTE] key is pressed, the operation of the mode
selected in 1) is performed.
6-6
Purpose
Operation test/check
Function (Purpose)
Used to perform fusing pressure release
and applying, and to check the operations
of the control circuits.
Section
Fusing
Operation/Procedure
1) Press [FUSER] key to highlight it.
2) Press [EXECUTE] key, and fusing pressure applying and fus-
ing pressure release are repeated.
During this period, the status of the fusing roller pressure is dis-
played.
6-90
Purpose
Setting
Function (Purpose)
Used to reset the machine to the factory
setting. (The scanner is set to the lock
enable position)
Section
Scanner
Operation/Procedure
1) Press [EXECUTE] key.
The scanner is shifted to the lock enable position and stopped.
7
7-1
Purpose
Setting
Function (Purpose)
Used to set the operating conditions of
aging.
Section
Others
Operation/Procedure
1) Select an item to be set with the touch panel key.
2) Press [EXECUTE] key.
The machine is rebooted in the aging mode.
The aging operation condition set by this mode is maintained here-
after unless the power is turned off or the setting is changed.
7-6
Purpose
Setting
Function (Purpose)
Used to set the operating intermittent aging
cycle.
Section
Operation/Procedure
1) Enter the intermittent aging operation cycle (unit: sec) with 10-
key.
2) Press [OK] key.
The time entered in procedure 1) is set.
* The interval time that can be set is 1 to 900 (sec).
The aging operation condition set by this mode is maintained here-
after unless the power is turned off or the setting is changed.
7-8
Purpose
Operation display
Function (Purpose)
Used to display the warm-up time.
Section
Operation/Procedure
Press [EXECUTE] key.
Counting of the warm-up time is started and the time required for
warm-up is displayed
* Interruption of counting by pressing [EXECUTE] key is inhibited.
Mode select button Content
TC1 Primary transfer (normal rotation)
TC1_R Primary transfer (reverse rotation)
TC2 Secondary transfer
Mode
select
button
Mode
display
Content NOTE
TC1 BLACK Monochrome
mode position
Black mode position  Color
mode position  Black mode
position  Drum separation
position  (Black mode
position)
(Repeated in this sequence.)
COLOR Color mode
position
FREE Non-transport
position
TC1_R BLACK Monochrome
mode position
Black mode position  Drum
separation position  Color
mode position  (Black
mode position) (Repeated in
this sequence.)
FREE Non-transport
position
COLOR Color mode
position
TC2 PRINT Print position Print position - Transfer
position - Non-transfer
position (Repeated in this
sequence)
FREE Non-transport
position
PRINT Fusing pressure
applying
Fusing pressure applying  Fusing
pressure release  (Fusing pressure
applying) The operation is repeated.
FREE Fusing pressure
release
AGING Aging operation setup
INTERVAL Intermittent operation setting
MISFEED DISABLE JAM detection ignoring setting
FUSING DISABLE Fusing unit ignoring setting
WARMUP DISABLE Warming up ignoring setting
DV CHECK DISABLE Developing unit ignoring setting
SHADING DISABLE Shading correction operation omitting setting
CCD GAIN FREE CCD gain adjustment omitting setting

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
