MX-3114N SIMULATION 6 – 26
23-80
Purpose
Operation test/check
Function (Purpose)
Used to check the operation of paper feed
and paper transport in the paper feed sec-
tion and the paper transport section. Used
to output the list of the operation status of
the sensor and the detectors in the paper
feed section and the paper transport sec-
tion.
Section
Paper feed, Paper transport
Operation/Procedure
When [EXECUTE] key is pressed, the timing list of paper feed and
paper transport is outputted.
Used to print the operations timing list of the sensors and detectors
in the paper feed and transport section.
The timing list of paper feed and paper transport operations of the
latest job (copy or print) on the final paper is printed.
Since the paper feed and paper transport routes differ depending
on the used paper feed tray and the print operation mode, the sen-
sor and the detectors and the operation timing also differ.
24
24-1
Purpose
Data clear
Function (Purpose)
Used to clear the jam counter, and the trou-
ble counter. (After completion of mainte-
nance, clear the counters.)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-2
Purpose
Data clear
Function (Purpose)
Used to clear the number of use (the num-
ber of prints) of each paper feed section.
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-3
Purpose
Data clear
Function (Purpose)
Used to clear the finisher, RSPF, and the
scan (reading) unit counter.
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-4
Purpose
Data clear
Function (Purpose)
Used to clear the maintenance counter, the
printer counters of the transport unit and
the fusing unit. (After completion of mainte-
nance, clear the counters.)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
JAM CODE Jam code
DATA/TIME Jam happened date and time
MODE Mode at the time of jam happened
SIZE Paper size
TYPE Paper type
PIC TRAY Paper feed tray
OUT TRAY Output tray
SECTION
Operation content (Trigger name - Detection operatopn or
load operation name)
STANDARD Reference value (ms)
JAM-1
Operation timing (ms) of the paper before one sheet of the
jam
MACHINE Machine JAM counter
SPF RSPF JAM counter
TROUBLE Trouble counter
TRAY1 Tray 1 paper feed counter
TRAY2 Tray 2 paper feed counter
TRAY3 Tray 3 paper feed counter
TRAY4 Tray 4 paper feed counter
MFT TOTAL Manual paper feed counter (Total)
MFT HEAVY Manual paper feed counter (Heavy paper)
MFT OHP Manual paper feed counter (OHP)
MFT ENV Manual paper feed counter (Envelope)
ADU ADU paper feed counter
SPF RSPF document feed counter
(No. of discharged sheets)
SCAN Scan counter
STAPLER Staple counter
PUNCHER Puncher counter
STAMP Stamp counter
COVER Document cover open/close counter
HP_ON Number of scanner HP detection
OC LAMP TIME Total lighting time of the scanner lamp
Item/Display Content
Maintenance MAINTENANCE
ALL
Maintenance counter (Total) (Counter)
Maintenance counter (Total)
(Number of use days)
MAINTENANCE
COL
Maintenance counter (Color) (Counter)
Maintenance counter (Color)
(Number of use days)
